Corrugated Cardboard Flute Lamination Machine Corrugated Carton Box Laminating Machine Paperboard Laminating Machine

Basic Info

Model NO.	DCL-M1300 / M1700
Membrane Material	PVC Film
Plastic Film Mulching Modes	Cold Laminating
Performance	Waterproof
L/D Ratio for Screw	32:1
Max Extrusion	260kg/H
Coating Width	600-1250mm
Adopt Material	Non Woven/ BOPP/Aluminum Foil
Transport Package	Wooden Case
Specification	L 9800* W 8000* H 3200mm / L9600*W10000*H3250mm
Trademark	TINUO
Origin	Zhejiang
HS Code	8451800002
Production Capacity	500PCS/Year

Product Description

High Speed Extrusion Hot Melt Lamination MachineProduct Description

1.Machine Procedure Raw material feeding -> Automatic tension -> Corona equipment -> Composite extruding -> Compounding processing -> Cooling -> Rewinding2.Product Sample

3.FeaturesThis series hot melt adhesive laminating machine is used for producing self-adhesive products, such as self-adhesive tape, double-adhesive tape, foam tape, aluminum foil tape, clean tape, masking tape, etc. It also suitable for laminating different materials, such as non-woven, filter materials, shoes materials, medical material, label, film, etc.1.Applicable coating film resin: Coating grade like LDPE, PP, EVA, EAA etc.2.Based material: Non Woven Fabric, Paper (30~425g/m2 ) , Textile Fibre , Knited Mesh, BOPP, BOPET.3.Inter-layer: Aluminium Foil, CPP, BOPPProduct Parameters

4.Machine Technical Data

SN	Item	Specification
1	Extrusion die width	1400mm / 1600MM
2	Coating width	600-1250mm / 900-1600MM
3	Max coating speed	80-150m/min / 100~150m/mi
4	Adopt material	Non woven/ BOPP/Aluminum foil
5	Coating thickness	0.01-0.05mm / 0.008-0.05mm
6	Inaccuracy thickness of coating film	±6% / ±5%
7	Setting range of Auto-tension	10-200kg/ 10-150kg /entire width (constant tension)
8	L/D ratio for screw	32:1
9	Rewinding roll diameter	Ø1300mm
10	Compound cooling roller	Ø500×1300mm / Ø500×1700mm
11	Max extrusion	260kg/h / 200kg/h
12	Total power	130KW
13	Working power	70-80kw / 80-95kw
14	Overall size	L 9800* W 8000* H 3200mm / L9600*W10000*H3250mm
15	Weight of Machine	15000KGS (40HQ*1, 20HQ*1)

Company Profile

Tinuo is a comprehensive mechanical manufacturing enterprise with research, development, production and sales, which specializes in making one full line Biodegradable Bag Making machinery. In order to create more economic and offer the one-step service, we collect all the knowledge and resource to service our customers with complete solution in Eco package industry in our field, including the paper bag machine, printing machine, non-woven production line, non-woven bag making machine.Closely with international advanced technology production technology, Tinuo has more than 80 patents, due to the changing of market demands, Willing and able to customize the machines. We are ISO9001:2000 certified cooperation, And our products has CE, B.V, SGS and GMC .... With rich technology and capital resources, we pay high attention to the new product innovation.

Our business covers world markets, especially good at South America, Middle East and North America. Till now Tinuo has signed an agency cooperation with including Chile, Egypt, South Africa, turkey, Lebanon ,and many other countries, more timely and roundly to provide customers with overseas technical help. Annual output value over $15 million, which makes it keep the leading position in this field in China land.

FAQ

Q1. How to install and operate the machine?

Due to the Global Epidemics we can not send the engineer , will provide the manual and installation video.

After the global epidemic end, The seller will send 1 engineer to install, test the production line and train customers' workers in buyers' factory. It will take 1 week for whole installation and training.

Q2. What should we charge for your engineer?

The buyer should cover engineers' salary, visa cost, round-trip air tickets, accommodations, transportation in buyers' country, food, medical care, safety cost, and related cost happens in buyers' country. Also, the buyer should prepare enough labor, electric wire outside the control panel and tools for installations.Engineer's salary is USD 80/day, depending on how the engineer make you satisfied. The date he arrives and leaves shall be counted as paid day.

Q3. How long is your machine's warranty period?

Warranty period for the delivered equipment will be 12 months after completion of erection but not later than 18months after shipment. In case any item proves to be defective and the damage is confirmed by seller's technicians within this period, the seller will at their choice either send engineer to repair or supply a new one for replacement free of charge on the basis of CNF delivery.

The above item does not include the parts, which have regular spares or the parts damaged from normal wear, abnormal operation, improper maintenance and inadequate civil works. The seller is not liable for any production loss under any circumstances.

Q4. How do we solve the machine problem after your engineer leaving?

Generally speaking, there will be no problem after finish installing. In case you have any problem. You can contact our after sales specialist at any time. Engineers will help to take a solution video according your description.

Q5. How do you arrange packing for machine?

As per export standard, they will also be treated before delivery against damage and rusting.
