Automatic Flute Laminating Machine for Paperboard

Basic Info

Model NO.	1300
Classification	Cold Laminating Machine
Application	Particle Board, Fiberboard, Plywood, Aluminium Plate, Packaging Paper, Film Material, Color Printing, Soft Board
Driven Type	Electric
Automatic Grade	Automatic
Membrane Material	Paper
Plastic Film Mulching Modes	Cold Laminating
Performance	Anti Wrinkle
Max. Paper Size (W×l	1300*1100
Min. Paper Size(W×l)	400*400
Surface Paper	200-500 G/M2
Machine Speed	120m/Min
Precision	1.5mm
Transport Package	Plastic Film Packaging
Specification	1300
Trademark	canghai
Origin	Hebei
Production Capacity	100 Set/Year

Product Description

automatic flute laminating machine for paperboard Introduction: 1.Suitable for laminating of cardboard and corrugated cardboard in 150-600 g/m2 . 2.The vacuum suction-type feeding system can lead the paper accurately into the machine;cycle stacking planes in a state of non-stop the next batch of paper stack well, so that more efficient. 3.Using suction automatic feeding of bottom sheet, according to the main machine operating speed, continuous automatic tracking. 4.The machine operation is stable, surface paper with corrugated paper joint very accurate. The corrugated paper never pull ahead, surface paper's location is easy adjust. 5.Machine uses touch-screen/PLC/servo motor control system, double frequency control type , the circuit system is stable, and can automatically display the failure alarm. 6.Automatic gluing, and the glue can be used circulatory, avoid glue waste. 7.Measure roller line-speed design scientifically, avoid glue fly out when the speed is high. 8.Pressure rollers adopt unilateral adjustment, convenient and fast. 9.Cleaning type : bottom roller is extruded by rubber roller to clean the bottom laminating pressure roller, ensure the cleaner on the reverse of the bottom paper . Make glue etc. foreign matter after washing direct - 2 - subside in tank. At the same time , adopting the gear and chain to control the lifting of tank, can take out the tank easily and convenient to wash . 10.The pressure conveyor adopt floating movable structure , total length 5m , equipped with 28 paper pressing rollers , make the cardboard uniform bearing strength in pressing process. 11.Counter designs scientifically, easy recording the amount you have been worked. 12.Small pressure table (optional) . length 2.5m , big pressure table length 5mTechnological parameter

Model	CH-1300-B	CH-1450-B	CH-1550-B	CH-1650-B	CH-1800-B
Max laminating size	1300mm×1250mm	1400mm×1250mm	1500mm×1250mm	1600mm×1250mm	1800mm×1400mm
Min laminating size	400mm×400mm	400mm×400mm	400mm×400mm	400mm×400mm	400mm×400mm
Economic speed	0-100sheets/min	0-100sheets/min	0-100sheets/min	0-100sheets/min	0-100sheets/min
Laminating precision	±1.5	±1.5	±1.5	±1.5	±1.5
Power	10kw	12kw	12kw	12kw	12kw
Size	13.5m×2m×2.4m	13.5m×2.05m×2.4m	13.5m×2.15m×2.4m	13.5m×2.25m×2.4m	13.5m×2.45m×2.4m
Weight	About 4.8t	About 5t	About 5.2t	About 5.4t	About 5.4t
Bottom paper thickness	A/B/C/E flute, 3/4/5 layer , less than 12mm thickness
Surface paper gram	150-600 g/m2
